Steam Process Mastery: COVNA Industrial Valve Solutions
As global industries accelerate decarbonization, steam remains a critical energy medium with 68% of industrial heating relying on steam systems (IEA 2023). COVNA delivers precision-engineered steam valves that empower safe and efficient thermal energy transfer across temperature ranges from 150°C to 580°C.
Mission-Critical Steam Applications
1. Oil & Gas Refining
Catalytic Cracking: High-pressure steam control valves (ANSI Class 150-2500) for FCCU reactor-regenerator systems
Pipe Tracing: Self-acting thermostatic steam traps maintain optimal viscosity in heavy crude pipelines
Tank Heating: Pilot-operated steam regulators with ±0.5 bar pressure stability
2. Chemical Processing
Reactor Jacket Heating: Triple-offset steam isolation valves with 100,000+ cycle durability
Distillation Columns: Multi-stage pressure reducing stations with anti-water hammer design
Heat Exchangers: Steam control valves with condensate drainage ports (Kv: 5-450)
3. Pulp & Paper Manufacturing
Yankee Dryer Systems: ASME B16.34 certified steam valves for 20 bar dryer drum operations
Black Liquor Recovery: Lined plug valves resisting caustic condensate (pH 12-14)
Tissue Drying: Fast-acting (≤1s) solenoid valves for steam shower systems
4. Cross-Industry Thermal Management
Pharmaceutical CIP/SIP processes
Food & Beverage sterilization autoclaves
Rubber vulcanization line steam control
COVNA Steam Valve Technology Edge
Intelligent Pressure Regulation
AI-Powered PID Controllers: Auto-compensate for load fluctuations (0-100% turndown ratio)
Real-time Steam Quality Monitoring: Integrated temperature/pressure transmitters (4-20mA/HART output)
Extreme Condition Resilience
Materials: ASTM A351 Gr. CF8M trim | Inconel 625 bellows seals | Graphite spiral-wound gaskets
Performance:
• 550°C continuous operation
• 50,000+ thermal shock cycles
• 98 dB(A) noise reduction
Safety by Design
SIL 3-certified emergency shutoff (ESD) systems
Live-loaded stem packing (ISO 15848-1 fugitive emission compliance)
Steam jacket-ready bodies for cryogenic ambient protection
Technical Specifications Spotlight
| Parameter | COVNA CXT Series | Industry Standard |
|---|---|---|
| Max Pressure | 42 MPa | 26 MPa |
| Leakage Class | ANSI VI | ANSI IV |
| Actuation Speed | 0.3-15s programmable | Fixed 2-5s |
| Maintenance Interval | 50,000 hrs MTBF | 15,000-30,000 hrs |
Case Study: Provided 356 steam control valves for Shell’s Pernis refinery upgrade, achieving 22% energy savings through precise steam network optimization.
Why Global Operators Trust COVNA
✅ Smart Steam Ecosystem
IIoT-enabled valves with predictive maintenance alerts
Digital twin integration for system simulation
✅ Lifecycle Cost Control
30% thicker body walls vs. API 602 requirements
Rotatable trim modules for partial refurbishment
✅ Global Compliance
PED 2014/68/EU | ASME B31.1 | TRD 100/200
ATEX/IECEx for hazardous area installations
✅ Rapid Deployment
48hr emergency spare parts dispatch
On-site steam system efficiency auditing
